Irritrol KD400-EXT KD2 Series Outdoor Controller, 4-Station

Irritrol

Controllers & Timers Residential Outdoor Controllers

Irritrol KD400-EXT KD2 Series Outdoor Controller, 4-Station

Name: Irritrol KD400-EXT KD2 Series Outdoor Controller, 4-Station
Brand: Irritrol
SKU: KD400-EXT
Price: 399.00 AED
Availability: InStock

SKU: KD400-EXT

Warranty 2 years

Dhs. 399.00

In stock

Product summary

The Irritrol KD400-EXT is a KD2 Series outdoor residential irrigation controller with 4 stations. It is designed for automatic, semi-automatic, and manual irrigation scheduling while keeping the familiar Irritrol controller interface. The outdoor KD2 format is suitable for residential and light landscape irrigation systems that need flexible scheduling, weather-sensor compatibility, rain-sensor readiness, and durable outdoor installation.

Key features

4-station outdoor KD2 Series controller
Three independent programs for different watering schedules
Automatic, semi-automatic, and manual operation
Multiple watering day options, including days-of-week, odd/even dates, and repeating interval schedules
Compatible with Climate Logic weather sensing and SMRT Logic remote/app-based control accessories
RainSensor-ready with sensor terminal and bypass switch
Self-diagnostic electronic circuit breaker for valve or field-wire shorts
Non-volatile memory retains program information during power interruptions

Quick specifications

Stations: 4
Voltage: 220-240 VAC
Frequency: 50-60 Hz

Complete technical details

Stations: 4
Installation Type: Outdoor controller
Electrical Output per Station: 24 VAC, 0.4 amp maximum
Total Output: 24 VAC, 0.8 amp maximum including master valve
Transformer Output: 24 VAC, 1.25 amps
Transformer Input: 220-240 VAC / 50-60 Hz
Outdoor Dimensions: approximately 8 in H x 6 in W x 4.5 in D
Supported Accessories: Climate Logic weather sensor, SMRT Logic gateway, CRR remote system, RS1000/RFS1000/RS500 rain sensors, SR-1 pump start relay

Best used for

Residential irrigation systems
Outdoor controller replacements
Small to medium landscape zones
Installations needing weather-sensor or remote-control accessory compatibility

Compatibility and notes

Select the controller version with the voltage and transformer configuration required for the installation. KD2 input options vary by market configuration.
