Rain Bird 100PGA PGA Globe/Angle Valve, 1 in, Plastic, with Flow Control

Rain Bird

Valves PGA Valves

Rain Bird 100PGA PGA Globe/Angle Valve, 1 in, Plastic, with Flow Control

SKU: B30310

Model: 100PGA

Warranty 2 years
Dhs. 185.00
In stock

Product summary

A durable 1 in PGA Series irrigation valve for high-end residential and light commercial systems, with flow control, filtered pilot flow, slow closing, and optional pressure regulation.

Key features

  • Watertight body-to-bonnet seal
  • Rugged PVC and glass-filled nylon construction
  • Normally closed, forward-flow design
  • Filtered pilot flow helps resist debris and clogging
  • Slow-closing operation helps reduce water hammer
  • One-piece solenoid with captured plunger and spring
  • Non-rising flow-control handle
  • Manual internal bleed
  • Globe/angle installation flexibility within the PGA design
  • Accepts optional PRS-D pressure-regulating dial
  • Accepts a latching solenoid for compatible Rain Bird battery-operated controllers
  • Optional non-potable-water flow-control handle available

Quick specifications

Connection size
25 mm (1 in)
Connection type
NPT Female x NPT Female Threaded
Thread standard
NPT

Complete technical details
  • SKU: B30310
  • Manufacturer Model: 100PGA
  • Brand: Rain Bird
  • Valve Series: PGA
  • Valve Size: 25 mm (1 in)
  • Valve Type: Inline
  • Material: Plastic
  • Connection: NPT Female x NPT Female Threaded
  • Valve Options: Multi-drive screws; non-potable option available
  • Operating Pressure: 1.0 to 10.4 bar (15 to 150 psi)
  • Maximum Water Temperature: 43°C (110°F)
  • Flow Range without PRS-D: 0.5 to 34 m³/h (2 to 150 GPM)
  • Flow Range with PRS-D: 1 to 34 m³/h (5 to 150 GPM)
  • Solenoid: 24 VAC, 50/60 Hz
  • Inrush Current: 0.41 A (9.9 VA)
  • Holding Current: 0.14 A (3.43 VA)
  • Coil Resistance: 30–39 ohms
  • Dimensions: 184 × 140 × 83 mm (7-1/4 × 5-1/2 × 3-1/4 in)

Best used for
  • High-end residential irrigation
  • Light commercial irrigation
  • Valve manifolds requiring adjustable flow control
  • Systems using optional PRS-D pressure regulation

Compatibility and notes
  • Use compatible 25 mm (1 in) NPT female-threaded connections.
  • Match controller output to the 24 VAC solenoid.
  • A compatible latching solenoid can be used with Rain Bird battery-operated controllers.
  • Solenoid handle is not included.
